The book shows a wide range of photos, from concerts to photoshoots, but also
some nice graphics
On the last page there is also apicture of the stage setup, with numbers 1-11
and some short text as an explanation. Below is this picture shown:
1 | Curtain truss (curtain track not shown) |
2 | Screen frame (15.80m x 4.00m) |
3 | Projection screen |
4 | Black masking to avoid LED striplights to spill light on projection screen (mounted drape clams to low chord of screen frame) |
5 | Upstage floor LED striplights |
6 | LED striplights mounted underneath main band riser |
7 | Band main riser (8.00m wide, 2.00m deep, 0.40m high / Covered with grey carpet / 0,30m High greay carpet skirting / Gap between skirtinh and stage floor is backli by LED strips underneath riser |
8 | Projection screen skirting illuminated by upstage floor LED strips |
9 | Front curtain (2.00m x 6.00m high, 10.07m wide cyc material) |
10 | Projector underhung from downstage truss |
11 | Downstage light + Projection truss |
